Wholesale cheap screw air compressor line filter air filter

RJ series precision filters provide users with high-quality compressed air filtration, specially used in laser cutting, bottle blowing, advanced spraying, food, electronics, petrochemical and other in

  • Working Pressure:7~16[ bar ]101.5~232[ psig ]
  • Free Air Delivery:24.7~1430[ cfm ]0.7~40.5[ m3/min ]
  • Working Power:7.5~250[ kw ]10~350[ hp ]
PRODUCT
GALLERY

DOWNLOAD DOCUMENT

ROCKY CATALOG 2025 VERSION Rocky RKY RKYII Portable compressor catalog Rocky High Pressure Breathing Air Compressor Catalog 2025 Rocky Medium High pressure air compressor catalog

Product Details

铝合金过滤器 (15).jpg

Product feature

1.Aluminum alloy material, corrosion resistance, long service life.

2. Pressure can reach 16 bar, high pressure adaptability.

3. High filtration accuracy, 5-100μm multi-stage filtration accuracy.

4. Low flow resistance design, energy saving 12-18%.

Technical Parameters


Filter model
Flow  Rate
(Nm³/min)
Interface c		H(mm)(mm)
Type of filter
element
RJ-005*0.7 1/2"165 74 FJ-005*
RJ-010*1.2 1/2”3/4"1"240 95 FJ-010*
RJ-020*2.3 1/2”3/4”1"280 95 FJ-020*
RJ-030*3.5 1-1/2"302 125 FJ-030*
RJ-050*5.7 1-1/2"421 125 FJ-050*
RJ-070*7.8 1-1/2"421 125 FJ-070*
RJ-110*11.6 2"550 170 FJ-110*
RJ-150*15.5 2"550 170 FJ-150*
RJX-200*20.8 2-1/2"640 205 FJX-200*
RJX-250*25.3 2-1/2"640 205 FJX-250*
RJX-300*30.8 3"792 205 FJX-300*
RJX-400*40.5 4"840 208 FJX-400*
