General Industrial 30% Energy Saving 132kw 175 HP Oil Free Screw Air Blower for Water Treatment

An oil-free screw blower is a core device that uses a pair of precision screw rotors to compress gas.

Working Pressure:0.4~2.0[ bar ]5.8~29[ psig ]
Free Air Delivery:1553~3954[ cfm ]44~112[ m³/min ]
Working Power:132[ kw ]175[ hp ]

DOWNLOAD DOCUMENT

ROCKY CATALOG 2025 VERSION Rocky High Pressure Gas Booster Compressor Catalog Rocky High Pressure Breathing Air Compressor Catalog 2025 Rocky Medium High pressure air compressor catalog

General Industrial 30% Energy Saving 132kw 175 HP Oil Free Screw Air Blower for Water Treatment

Product Details

Features and Advantages

1. High Efficiency and Energy Saving: A core advantage. Utilizing permanent magnet variable frequency technology

and internal compression principle, it saves approximately 30% more energy than traditional Roots blowers.

2. Absolutely Oil-Free: Delivers pure gas, meeting the needs of industries with stringent air quality requirements.

3. Low Noise and Vibration: Smooth operation with noise levels typically below 75 decibels, providing a more

comfortable working environment.

4. Intelligent Control: Integrated intelligent controller for real-time monitoring and easy maintenance.

5. Long Lifespan and Low Maintenance: The main unit is designed for a long lifespan; the main maintenance task is

replacing the filter element.

Technical Parameters

Oil-free Screw Blower BPM Series
Model	Power （kW）	Pressure（bar/kPa）	Volume flow（m³/min）	Pipe Diameter	Weight（kg）	Dimension (mm)
RK7.5BPM	5.5	0.4/40	4.0	DN150	700	1400×1100×1360
		0.6/60	3.2
RK10BPM	7.5	0.4/40	6.4	DN150	750	1400×1100×1360
		0.6/60	4.6
		0.8/80	3.5
RK15BPM	11	0.4/40	9.0	DN150	800	1400×1100×1360
		0.6/60	7.5
		0.8/80	6.0
		1.0/100	4.8
		1.2/120	4.0
		1.5/150	2.8
RK20BPM	15	0.4/40	13.6	DN150	1200	2200×1250×1900
		0.6/60	10.5	DN150	800	1400×1100×1360
		0.8/80	8.3
		1.0/100	6.7
		1.2/120	5.8
		1.5/150	4.5
RK25BPM	18.5	0.4/40	16.2	DN150	1250	2200×1250×1900
		0.6/60	13.1
		0.8/80	10.3	DN150	800	1400×1100×1360
		1.0/100	9.2
		1.2/120	7.5
		1.5/150	6.0
RK30BPM	22	0.4/40	22.0	DN150	1250	2200×1250×1900
		0.5/50	19.0
		0.6/60	16.0
		0.7/70	14.5
		0.8/80	13.0
		1.0/100	9.5	DN150	850	1400×1100×1360
		1.2/120	8.8
		1.5/150	7.0
RK40BPM	30	0.4/40	29.0	DN200	1750	2700×1400×1900
		0.6/60	26.0	DN150	1250	2200×1250×1900
		0.7/70	23.5
		0.8/80	21.5
		1.0/100	15.8
		1.2/120	12.5
		1.7/170	7.5	DN150	800	1400×1100×1360
RK50BPM	37kW	0.4/40	38.0	DN200	1750	2700×1400×1900
		0.5/50	35.0
		0.6/60	32.0
		0.8/80	26.0	DN150	1250	2200×1250×1900
		1.0/100	21.5
		1.2/120	15.5
		1.5/150	12.5
RK60BPM	45kW	0.4/40	44.0	DN200	1750	2700×1400×1900
		0.5/50	42.0
		0.6/60	38.0
		0.8/80	33.5
		1.0/100	26.0	DN150	1300	2200×1250×1900
		1.2/120	21.0
		1.5/150	15.5
		1.7/170	12.7
RK75BPM	55kW	0.4/40	55.0	DN200	1800	2700×1400×1900
		0.6/60	48.0
		0.7/70	44.0
		0.8/80	41.5
		1.0/100	35.0		1750
		1.2/120	31.0
		1.5/150	21.0	DN150	1350	2200×1250×1900
		1.8/180	16.5
		2.0/200	14.5
RK100BPM	75kW 225S/M	0.4/40	78.0	DN250	2200	3100×1500×2150
		0.6/60	68.0
		0.7/70	61.0
		0.8/80	55.0	DN200	1800	2700×1400×1900
		0.9/90	51.0
		1.0/100	47.0
		1.2/120	42.5
		1.5/150	34.0		1750
		1.8/180	27.0
		2.0/200	24.5	DN150	1400	2200×1250×1900
RK125BPM	90	0.4/40	98.0	DN300	2550	3300×1750×2350
		0.6/60	78.0	DN250	2200	3100×1500×2150
		0.8/80	68.0
		1.0/100	61.0
		1.2/120	50.0	DN200	1850	2700×1400×1900
		1.5/150	42.0
		1.8/180	34.0
		2.0/200	30.5
RK150BPM	110	0.4/40	113.0	DN300	2600	3300×1750×2350
		0.6/60	92.0
		0.8/80	78.0
		1.0/100	67.5	DN250	2250	3100×1500×2150
		1.2/120	60.0
		1.5/150	49.0
		1.8/180	41.5
		2.0/200	37.5
RK180BPM	132	0.6/60	112.0	DN300	2600	3300×1750×2350
		0.8/80	98.0
		1.0/100	81.0
		1.1/110	73.0
		1.2/120	71.0	DN250	2300	3100×1500×2150
		1.5/150	58.0
		1.8/180	48.0	DN200	1900	2700×1400×1900
		2.0/200	44.0
RK220BPM	160	0.4/40	180.0	DN300	3500	3600×2100×2350
		0.6/60	130.0
		0.8/80	111.0	DN300	2750	3300×1750×2350
		1.0/100	101.0
		1.1/110	89.0
		1.2/120	80.0
		1.5/150	70.0	DN250	2300	3100×1500×2150
RK250BPM	185	0.4/40	203.0	DN300	3500	3600×2100×2350
		0.6/60	154.0
		0.8/80	129.0
		1.0/100	110.0	DN300	2800	3300×1750×2350
		1.2/120	96.0
		1.5/150	83.0
		1.8/180	66.5
RK270BPM	200	0.4/40	212.0	DN300	3600	3600×2100×2350
		0.6/60	177.0
		0.8/80	144.0
		1.2/120	110.0	DN300	2800	3300×1750×2350
		1.5/150	90.0
		1.8/180	76.0
		2.0/200	66.0
RK300BPM	220	0.6/60	196.0	DN300	3600	3600×2100×2350
		0.8/80	159.0
		1.0/100	127.0
		1.5/150	100.0	DN300	2800	3300×1750×2350
		1.8/180	86.0
		2.0/200	73.0
RK350BPM	250	0.6/60	220.0	DN300	3800	3600×2100×2350
		0.8/80	182.0
		1.0/100	150.0
		1.2/120	125.0
		1.5/150	109.0	DN300	2700	3300×1750×2350
		1.8/180	95.0
		2.0/200	85.0
RK380BPM	280	0.8/80	206.0	DN300	3900	3600×2100×2350
		1.0/100	178.0
		1.1/110	162.0
		1.2/120	148.0
RK420BPM	315	1.0/100	195.0	DN300	4000	3600×2100×2350
		1.2/120	170.0
		1.5/150	130.0
RK480BPM	355	1.2/120	192.0	DN300	4100	3600×2100×2350
		1.5/150	160.0
RK540BPM	400	1.5/150	188.0	DN300	4200	3600×2100×2350
