Oil Free Oxygen Nitrogen Booster Oxygen/Natural Gas/Air Compressor

The oxygen compressor adopts a completely oil-free design, and friction seals such as piston rings and guide rings are made of special materials with self-lubricating properties.

  • Working Pressure:150[ bar ]2175[ psig ]
  • Free Air Delivery:176.5~4942[ cfm ]5~140[ m3/min ]
  • Working Power:4~22[ kw ]5.3~30[ hp ]

Product Details


Product Features

● PLC touch screen control, remote control optional.

● Inlet and outlet pressure overload, temperature overheating, cooling water failure, System will alarm and shutdown automaticly.

● Running time display, maintenance reminder.

● Self-contained water tank and circulation pump, no need for external piping. use antifreeze, no fear of low temperature.

● Small vibration, low noise, long life of wearing parts.

Technical Parameters

Model

Capacity

(m3/h)

Inlet P (Barg)Outlet P (Barg)

Motor Power

(Kw)

Rotating speedInlet SizeOutlet SizeDimension L*W*H(mm)Weight (kg)
RWWY(1-5)4-15054 1504.0470RC1/2"G5/81350*850*1100380
RWWY-10/4-150104 15055470RC1/2"G5/81350*1050*1100410
RWWY-15/4-150154 15075640RC1/2"G5/81350*1050*1100420
RWWY-20/4-150204 15011580RC1/2"G5/81350*1050*1100430
RWWY-25/4-150254 15011640RC1/2"G5/81350*1050*1100430
RWWY-30/4-150304 15015470RC1/2"G5/81350*1050*1100450
RWWY-35/4-150354 15015470RC1/2"G5/81350*1050*1100450
RWWY-40/4-150404 15015580RC1/2"G5/81350*1050*1100450
RSWY-45/4-150454 15018.5580RC1"G5/81450*1100*1250520
RSWY-50/4-150504 15018.5580RC1"G5/81450*1100*1250520
RSWY-55/4-150554 15018.5580RC1"G5/81450*1100*1250520
RSWY-60/4-150604 15022640RC1"G5/81450*1100*1250540
RSWY-65/4-150654 15022720RC1"G5/81450*1100*1250540
RSWY-70/4-150704 15022720RC1"G5/81450*1100*1250540
RWWY-75/4-150-II754 15015*2580RC1"G5/82800*1250*12001060
RWWY-80/4-150-II804 15015*2580RC1"G5/82800*1250*12001060
RWWY-85/4-150-II854 15015*2580RC1"G5/82800*1250*12001060
RSWY-90/4-150-II904 15018.5*2580RC1"G5/82900*1320*13001260
RSWY-95/4-150-II954 15018.5*2580RC1"G5/82900*1320*13001260
RSWY-100/4-150-II1004 15018.5*2580RC1"G5/82900*1320*13001260
RSWY-105/4-150-II1054 15018.5*2580RC1"G5/82900*1320*13001260
RSWY-1104-150-II1104 15018.5*2580RC1"G5/82900*1320*13001260
RSWY-1154-150-II1154 15022*2640RC1"G5/82900*1320*13001350
RSWY-12/4-150-II1204 15022*2640RC1"G5/82900*1320*13001350
RSWY-125/4-150-II1254 15022*2640RC1"G5/82900*1320*13001350
RSWY-130/4-150-II1304 15022*2720RC1"G5/82900*1320*13001350
RSWY-135/4-150-II1354 15022*2720RC1"G5/82900*1320*13001350
RSWY-140/4-150-II1404 15022*2720RC1"G5/82900*1320*13001350
