Air Compressor Precision Filter Air Filter Element BXG-050*

BXG series stainless steel precision filter (1.6Mpa) The shell is made of 304 stainless steel, the inner and outer layers are mirror polished, anti-corrosion, low resistance, widely used in various in

  • Working Pressure:7~16[ bar ]102~232[ psig ]
  • Free Air Delivery:35.3~1412[ cfm ]1~40[ m3/min ]
  • Working Power:5.5~250[ kw ]7.5~350[ hp ]

Product Details

Air Compressor Precision Filter Air Filter Element BXG-050*

BXG series stainless steel precision filter (1.6Mpa)

The shell is made of 304 stainless steel, the inner and outer layers are mirror polished, anti-corrosion, low resistance, widely used in various industrial gas filtration applications and gas sterilization treatment, such as semiconductor, metallurgy, medical, pharmaceutical, and food chemical industries and other industries.

Technical Parameters

Filter ModelCapacity(m3/min)Number of filter elementsFilter element modelImport and Export(Threaded Flange))HBarrel diameter
BXG-010*11E-161"36415076
BXG-020*21E-201"36416076
BXG-030*31E-241.5"40216089
BXG-050*51E-281.5"57221089
BXG-070*71E-321.5"57226089
BXG-110*11 1E-362"710340102
BXG-140*151E-40DN65710380133
BXG-180*201E-44DN801000380133
BXG-220*251K430DN80950380159
BXG-350*401K620DN10011501150159
